Description
Output power:
1kHz (THD+N=1%: 3Ω): 100W x 2 (20ms Burst)
1kHz (THD+N=1%: 4Ω): 120W x 2 (20ms Burst)
1kHz (THD+N=1%: 8Ω): 100W x 2 (20ms Burst)
High impedance: 100V line: 120W x 2 or 200W x 1
High impedance: 70V line: 120W x 2 or 200W x 1
I/O Connectors:
Mic/Line Input: Input 1-6: 3.5mm Euroblock (6-pin, balanced) x 3
Line Input: Input 7-8: Stereo RCA pin (unbalanced) x 2, Input 8: 3.5mm Stereo mini phone (unbalanced), Input 5-6: RCA pin (MONO SUM, unbalanced) x 4
Speaker Output: Barrier strip x 2 pairs
Line Out: LINE OUT: MONO RCA pin x2 (unbalanced)
Control ports: RJ-45 (for DCP4V4S, DCP1V4S , DCP4S), Remote (3.5mm Euro block 3-pin)
Input Level: Mic input: -56dBu (Sensitivity), -36dBu (Nominal), -8dBu (Max before clip) / Line input (unbalanced): -30dBV (Sensitivity), -10dBV (Nominal), +10dBV (Max before clip) / Line input (balanced): -24dBu (Sensitivity), -4dBu (Nominal), +24dBu (Max before clip)
Output Level: -10dBV (LINE OUT, Nominal)
Amplifier classl CLASS D
Power requirements: 100V, 120V, 230V – 240V, 50Hz / 60Hz
Power consumption: 60W (1/8 max power, 4Ω, AC100V, pink noise at all channels)
Dimensions:480x45x379mm
Net weight: 4.9kg (10.8lbs)
