Yamaha Line Array-Column Speaker-VXL1W-24

Description

Speaker type: Full-range, Bass reflex
Frequency range (-10dB): 77 Hz – 20 kHz *1, 98 Hz – 20 kHz *1 (with port cover)
Nominal coverage
H: 170°
V: 15°(+7.5° – -7.5°) (NORMAL), 20°(+7.5° – -12.5°) (WIDE)
Effective coverage (-10dB)
H: 180°
V: 25°(+12.5° – -12.5°) (NORMAL), 35°(+12.5° – -22.5°) (WIDE)
Components
LF-HF: 1.5” (3.75 cm) Cone × 24
Power rating
NOISE: 110 W
PGM: 220 W
PEAK: 440 W
Nominal impedance: 8Ω
SPL:
Sensitivity (1W; 1m on axis): 91 dB SPL (1 m/1 W) *1 *2 (91 dB SPL with port cover)
Peak (Calculated): 117 dB SPL (1 m) *3
I/O connectors: Euroblock (2 pin) × 2 (input: +/-) Max. wire size AWG 12 (3.3 mm²)
Protection circuit:
Load protection: Full-range power limiting to protecting network and transducers
Dust and water resistant: IP34 (IP35 with port cover)
Dimensions (W x H x D): W54 × H1212 × D104 mm (Speaker only), W54 × H1212 × D111.5 mm (With included bracket)
Weight: 5.5 kg (Speaker only)
